FEATURES:
- 73-key drawbar organ and stage piano
- Proprietary Virtual Circuit Modeling delivers authentic vintage organ character
- Sculpt your sound with intuitive drawbar controls
- 6-octave, weighted/balanced keyboard is perfect for playing all types of virtual instruments
- 2 ultra-realistic rotary speaker models
- Seamless Sound Switching patches while holding notes without the sound cutting off
- Great selection of additional instrument voices, including acoustic and electric pianos, DX-style FM synth sounds, strings, and brass
- Layer sounds with the Dual Keys section
- 9 onboard effects processors, including vibrato/chorus, reverb, delay, drive, and more
- USB-to-Host port: 2-channel audio/MIDI interface for DAW and computer audio integration
- USB-to-Device port: for connection of thumb drives, smartphones, tablets, etc.
- Dual 1/4-inch jacks for connecting secondary keyboards, mobile devices, and more
- 2 assignable 1/4-inch continuous controller pedal jacks
- 2 1/4-inch switch pedal jacks (sustain, assignable)
- L/Mono-R 1/4-inch inputs with Gain control
- 1/4-inch Headphones jack
- Internal power supply; IEC mains port
SPECIFICATIONS:
| Type | Stage Organ Keyboard |
|---|---|
| Sound Engine | Virtual Circuitry Modeling, 8 Operator FM Synthesis, AWM2 |
| Number of Keys | 73 |
| Type of Keys | Balanced Hammer Standard |
| Touch Sensitivity | Normal, Soft, Hard, Wide, Fixed |
| Other Controllers | Pitchbend Lever, Modulation Lever, 9 x Drawbars |
| Polyphony | 128 Notes |
| Presets | 80 x User Presets, 80 x Factory Presets ; 6 x Organ Voices, 139 x Keyboard Voices ; VCM/FM Organ, Grand Pianos, Electric Pianos |
| Effects | 9 x FX Processors: Rotary Speaker, Vibrato/Chorus, Delay, Guitar Amp, Reverb, Drive |
| Audio Inputs | 2 x 1/4″ (L/mono,R) |
| Audio Outputs | 2 x 1/4″ (L/mono,R) |
| Headphones | 1 x 1/4″ |
| USB | 1 x Type B, 1 x Type A |
| MIDI I/O | In/Out/USB |
| Pedal Inputs | 1 x 1/4″ (sustain), 1 x 1/4″ (assignable), 2 x 1/4″ (foot controller) |
| Pedal Included | Yes, FC3A (sustain) |
| Display | LCD |
| Power Supply | Standard IEC AC Cable |
| Height | 5.6″ |
| Width | 42.75″ |
| Depth | 14″ |
| Weight | 29.6 lbs. |
| Manufacturer Part Number | YC 73 |
