Features
- 16 x 8 USB-C Interface – Ultra-low-latency custom drivers (macOS/Windows)
- Eight MAX-HD Mic Preamps with 75 dB Gain – Transparent, low-noise recording for large sessions
- A Total of 14 Line Inputs – for easy connection of mic pres, synths, mixers, and other line-level devices:
- 6 front panel XLR/TRS (combo jacks 3–8)
- 8 rear panel TRS inputs with switchable 4 dBu / -10 dBV operation
- Dual Fender-Designed Instrument Inputs – Optimized for guitars, basses, and other instruments
- Balanced TRS Outputs & Headphone Monitoring – Professional-quality, flexible monitoring
- Loopback Audio – Streaming, podcasting, and mix routing
- Standalone Mixer Mode & Mic Pre Mode – Analog mixing or 8-channel mic preamp operation
- DC-Coupled Outputs – Integrate modular synths and analog gear
- 5-Pin MIDI I/O – Hardware integration without external MIDI interface
- Fender Studio Pro Perpetual Included – Professional DAW with Mustang and Rumble plug-ins
- Built-in MyFender Access – Quick setup, registration, and support
General
Product Name
Quantum LT 16 USB-C Audio Interface
Series
Quantum
Color
Black
Microphone Inputs
Connection Type
XLR Female (Combo), Balanced
Frequency Response
20 Hz to 20 kHz
Dynamic Range
115 dB
EIN
-128.6 dBu
THD+N
0.001 %
Gain Range
75 dB
Maximum Input Level
+18 dBu
Phantom Power
+48 VDC
Line Inputs
Connection Type
1/4″ TRS Female
Frequency Response
20 Hz to 20 kHz
Dynamic Range
115 dB (+4 dBu) / 113 dB (-10 dBV)
THD+N
0.001 % (+4 dBu) / 0.0009 % (-10 dBV)
Maximum Input Level
+18 dBu
Instrument Inputs
Connection Type
1/4″ TS
Frequency Response
20 Hz to 20 kHz
Dynamic Range
114 dB
THD+N
0.003%
Maximum Input Level
+22 dBu
Line Outputs
Connection Type
1/4″ TRS Female
Maximum Output Level
+18 dBu
Main Outputs
Connection Type
1/4″ TRS Female
Headphone Outputs
Connection Type
1/4″ TRS Female
Frequency Response
20 Hz to 20 kHz
Dynamic Range
114 dB
THD+N
0.01 %
Maximum Output Level
142 mW/Channel (60Ω Load)
MIDI I/O
Connection Type
5-Pin Female DIN
Power
Voltage
120V
Voltage Requirements
100-240 VAC, 50-60 Hz
Digital Audio
Connectivity
USB-C®
Bit Depth
24 Bit
Dynamic Range
115 dB
Supported Sample Rates
44.1, 48, 88.2, 96, 176.4, 192 kHz (kHz)
Measurements
Height
1.75″ (44.45 mm)
Depth
5″ (127 mm)
Width
19″ (483mm)
Weight
4.8 lbs. (2.2 kg)
