Hybrid XO2-3500-8 Passive Crossover – 2 Way

The Hybrid+ XO2-3500 is a universal, DIY, 2-way passive crossover suitable for enclosure design enthusiasts and it can be used as a replacement crossover for most 8Ω, 2-way speaker cabinets, ranging in size from 6″ to 15″.
The XO2-3500 features 12dB/Octave filters, with a switch selectable high frequency attenuation and a PTC protection. Installing the XO2-3500 is extremely easy with the screw-in terminal block connector.

XO2-3500
2-Way Passive Crossover, 8Ω LF – 8Ω HF
Crossover Frequency: 3500Hz
Power Handling: 250W rms
LF Impedance: 8Ω
HF Impedance: 8Ω
LF Filter: 12dB / Octave
HF Filter: 12dB / Octave
HF Attenuation: Switchable, -4dB, -6dB and -8dB
HF Protection: PTC (Positve Temperature Control)
Connectors: Screw-in terminal block connector
Construction: 1.5mm fiberglass PCB
