- Passive DI Box with stereo input and summed mono output
- Custom-built Midas transformer for highest signal integrity
- High headroom design offers superior sound quality
- Passive design does not require any power supply
- Stereo input on 1/8″ TRS and RCA connectors
- Fully adjustable level control for both channels
- Industry standard XLR connectors for highest reliability
- Earth Lift switch eliminates ground loop problems
- Fully transformer-isolated design ensures electrical separation
- Ultra-low noise and ultra-linear system for highest signal integrity
- Aluminium extrusion casing with protective rubber corners
- Compact and rugged design
Specification
Inputs
| Connectors | RCA unbalanced, 1/8″ TRS |
| Impedance | 7 kΩ |
Outputs
| Connector | XLR, balanced |
| Impedance | 170 Ω |
System
| Frequency response | 10 Hz to 91 kHz (± 1 dB) |
| THD + N (distortion) | <0.03% @ 1 kHz, +4 dBu |
| Signal-to-noise ratio | >120 dB @ 1 kHz, +4 dBu |
| Power requirement | Passive |
Physical
| Dimensions (W x D x H) | 64 x 118 x 112 mm
(2.5 x 4.7 x 4.4″) |
| Weight | 0.47 kg (1.0 lbs) |
