- Active DI Box for general purpose and multimedia applications
- Custom-built Midas transformer for highest signal integrity
- High headroom design offers superior sound quality
- Powered from console +48 V phantom or internal battery (not included)
- Automatic switchover to battery if phantom power fails
- Matches the level and impedance with unity gain without loading the source
- Switchable input attenuation for guitar, line and speaker levels
- High quality industry standard XLR and high impedance 1/4″ TRS connectors
- Earth Lift switch eliminates ground loop problems
- Fully transformer-isolated design ensures electrical separation
- Ultra-low noise and ultra-linear system for highest signal integrity
- Aluminium extrusion casing with protective rubber corners
- Compact and rugged design
Audio Connections
| Input | 1 x XLR, unbalanced 1 x 1/4″ TS, unbalanced |
| Input Impedance | > 250 kΩ |
| Thru | 1 x 1/4″ TS, unbalanced |
| Output | 1 x XLR, balanced |
| Load Impedance | > 600 Ω |
| Maximum Input level | +10 / +30 / +50 dBu |
System
| Frequency Response | 10 Hz to 90 kHz, ±3 dB |
| THD+N | < 0.02 % @ 1 kHz, 0 dBu |
| Noise Leve | < -112 dBu |
| PAD Switch | 0 / -20 / -40 dB |
Power Supply
| Phantom power | 18 V DC to 48 V DC |
| Battery | 9 V Blockcell 6LR61 |
Dimension / Weight
| Dimensions (W x D x H) | 118 x 120 x 64 mm (4.6 x 4.7 x 2.5″) |
| Weight | 0.56 kg (1.2 lbs) |
