- Line level splitter sends single input signal to 5 outputs
- High headroom design offers superior sound quality
- Passive design does not require any power supply
- Industry standard XLR connectors for highest reliability
- Ultra-low noise and ultra-linear system for highest signal integrity
- Aluminium extrusion casing with protective rubber corners
- Compact and rugged design
Inputs
| Connector | XLR, balanced |
Outputs
| Connectors | 5 x XLR, balanced |
System
| Frequency response | 20 Hz to 22 kHz (± 0.05 dB) |
| THD + N (distortion) | < 0.01% @ 1 kHz,+4 dBu |
| Signal-to-noise ratio | 121 dB |
| CMRR | 98 dB typical |
| Insertion loss | 0.05 dB @ 100 kΩ, 0.7 dB @ 600 Ω |
| Power requirement | Passive |
System
| Dimensions (W x D x H) | 118 x 112 x 64 mm (4.6 x 4.4 x 2.5″) |
| Weight | 0.43 kg (0.9 lbs) |
