The Neumann KH 120 II is the upgraded successor to the renowned KH 120 A, engineered for even greater accuracy, deeper bass, and modern connectivity. Designed and manufactured in Germany, it provides outstanding clarity and transient response, making it ideal for professional mixing, mastering, and broadcast applications.
The KH 120 II features dual-class-D amplifiers (145 W + 100 W) powering a 5.25″ woofer and 1″ titanium fabric dome tweeter, achieving exceptional low distortion and wide dynamic range.
It includes DSP-based electronics for phase linearization, room alignment via the Neumann MA 1 Automatic Monitor Alignment system, and AES67 network audio compatibility (Dante- and Ravenna-compliant) in the EU/KR version.
The precisely molded waveguide (MMD™) ensures consistent directivity, while the solid aluminum cabinet minimizes resonances. The KH 120 II delivers a linear frequency response from 44 Hz to 21 kHz (±3 dB) and SPL up to 118.4 dB (pair, 1 m).
Key Features:
-
Compact bi-amplified active studio monitor (single unit)
-
DSP-controlled electronics with linear-phase crossovers and delay alignment
-
AES67 network audio interface (Dante/Ravenna compatible – EU/KR version)
-
Compatible with Neumann MA 1 calibration system for automatic room alignment
-
Precision-engineered 5.25″ woofer + 1″ titanium fabric dome tweeter
-
Frequency response: 44 Hz – 21 kHz (±3 dB)
-
Maximum SPL (pair, 1 m): 118.4 dB
-
Amplifier output power: 145 W (woofer), 100 W (tweeter)
-
Input options: Analog XLR + AES67 (network audio)
-
Mounting options: Rear threaded points and bottom mount for brackets or stands
-
Aluminum cabinet for optimal resonance control
-
Universal 100–240 V AC power supply
Specifications:
-
Type: 2-way bi-amplified active nearfield monitor
-
Woofer: 130 mm (5.25″)
-
Tweeter: 25 mm (1″)
-
Amplifier Power: 145 W LF + 100 W HF
-
Frequency Response: 44 Hz – 21 kHz (±3 dB)
-
Max SPL: 118.4 dB (pair, 1 m)
-
Inputs: XLR analog / AES67 network (EU/KR version)
-
Mains Voltage: 100–240 V AC, 50/60 Hz
