Features
- Voice Coil Cooling: Ferrofluid
- Shipping Weight: 38 oz.
- Net Weight: 33.6 oz.
- Horn Coupling Threads: Standard 1 3/8″ / 18″
- Horn Coupling Diameter: .938″ (23.8 mm)
- Dimensions: 3.54″ (90 mm) diameterx 2.40″ (61 mm) depth
- Flux Density: 11,500 gauss (1.15T)
- Voice Coil Material: Edge-wound ribbon withhigh temp Kapton bobbin
- Voice Coil Diameter: 1.4″ / 34.4 mm
- Diaphragm: Commercially pure titanium
- Lowest Recommended Crossover: 2,000 Hz at 12 dB / Octave
- Recommended Crossover: 1,800 Hz at 12 dB / Octave
- Frequency Response: 1.5 kHz to 20 kHz
- Nominal Efficiency: 30%
- Sensitivity: 104 dB SPL 1 Watt at 1 meterOn-axis on 90º H x 45º V horn
- Power Capacity 1000 Hz to 20,000 Hz: 120 W peak60 W program30 W continuous
- DC Resistance: 6.8 Ohms
- Minimum Impedance: 7.1 Ohms
- Nominal Impedance: 8 Ohms
- Throat Parameter: .938″ / 23.8 mm
- 1.4″
- Packed Weight: 2.26 lb (1.02 kg)
- Packed Length: 4.25″ (10.79 cm)
- Packed Width: 4.25″ (10.79 cm)
- Packed Height: 3.25″ (8.26 cm)
