Rode RODECaster Video Core A/V Production Console

The RØDECaster Video Core delivers the powerful video and audio processing of the RØDECaster Video series in a compact, screen-free format.

It is designed for software-based operation through the free RØDECaster App or integration with a RØDECaster Pro II or RØDECaster Duo using RØDECaster Sync. This makes it ideal for permanent studios, video podcasts and creators who already use a computer or dedicated audio production console.

Three Full HD HDMI inputs and a flexible USB-C video input allow switching between four video sources. Five custom scenes can combine cameras, graphics, overlays and media in picture-in-picture, split-screen and other layouts.

Key Features

• Software-controlled video and audio console
• Three Full HD HDMI inputs
• One UVC-compatible USB-C video input
• One configurable HDMI output
• Switch between four video sources
• Five fully customisable scenes
• Full HD video up to 1080p60
• Automatic frame-rate conversion
• Intelligent audio-based automatic switching
• Media playback and graphic overlays
• Picture-in-picture and split-screen layouts
• Automatic chroma and luma keying
• Custom fades, wipes and transitions
• Program and isolated source recording
• Direct Ethernet streaming
• UVC video output to a computer
• NDI network camera support
• DaVinci Resolve timeline export
• Controlled through the RØDECaster App
• RØDECaster Sync compatibility
• Designed and manufactured in Australia

Audio Features

• Nine simultaneous stereo audio channels
• Two Neutrik XLR/6.35mm TRS combo inputs
• Ultra-low-noise Revolution Preamps
• Up to 76dB microphone gain
• 48V phantom power
• Two independent headphone outputs
• Dual USB-C audio interfaces
• 24-bit/48kHz audio recording
• Individual audio routing and processing
• APHEX VoxLab processing
• Compressor and equaliser
• Noise gate and high-pass filter
• De-esser and panning
• Aural Exciter, Big Bottom and Compellor processing

Specifications

Product Type: Software-controlled audio and video production console

Simultaneous Video Sources: Four

HDMI Inputs: Three HDMI 1.4b Type-A inputs

USB Video Input: One UVC-compatible USB-C input

NDI Inputs: Up to four through Ethernet

Video Outputs: One HDMI, one UVC and one NDI output

Maximum Video Resolution: 1920 × 1080 at 60fps

Program Recording: Up to 1080p60

Isolated Recording: Up to four sources at 1080p30

Video Recording Format: H.264/AVC in MP4 container

Audio Recording Format: WAV

Custom Scenes: Five

Program Layers: Nine

Audio Mixer: Nine stereo channels simultaneously

Analogue Inputs: Two XLR/6.35mm TRS combo inputs

Microphone Gain: Up to 76dB

Phantom Power: 48V

Headphone Outputs: Two 6.35mm outputs

Audio Resolution: 24-bit/48kHz

Network Connection: Gigabit Ethernet

Wi-Fi: No

Bluetooth: No

Wireless Microphone Receivers: No built-in receivers

Internal Storage: 24GB, with approximately 20GB user-configurable

Recording Media: Compatible external USB storage device formatted as exFAT

Streaming Protocols: RTMP and RTMPS

Computer Compatibility: macOS 11 or later, Windows 10 version 1803 or later, and Windows 11
