Delivering deep, thunderous bass performance, the 2200W 18″ Powered Subwoofer is engineered for professionals seeking exceptional low-end reinforcement in portable and installed PA applications. Featuring cutting-edge Klark Teknik Digital Signal Processing (DSP), this subwoofer offers enhanced clarity, protection, and dynamic control in any live or playback environment.
Built with a high-excursion 18″ woofer in a robust bass-reflex enclosure, it delivers powerful output with minimal distortion. The DSP includes intelligent limiting, crossover, and time alignment functions, ensuring consistent performance across various configurations.
Feature
- Band pass powered subwoofer for portable PA and installation applications
- 2,200 Watt power featuring Klark Teknik Class-D technology
- High excursion 18″ low frequency driver with 4″ voice coil and double suspension
- Bass boost and polarity switch for accurate low frequency system integration
- Birch plywood enclosure with hard wearing semi matt black paint finish
- Rugged powder coated perforated steel mesh grille
- 36 mm pole mount to support satellite speaker
- Plated steel castors with rubber tyres
-
Specification
Model
Components 1 x 18″ LF driver Connectors Input: 2 x female XLR wired pin 2 hot
Thru: 2 x male XLR wired pin 2 hot
IEC mains connector with integrated fuseholderControls
Controls Level, Polarity, Boost, Boost Frequency System Data
Frequency Range 40 Hz–100 Hz ±3 dB
30 Hz–150 Hz -10 dBDispersion @-6 dB pts N/A Max SPL (peak) 134 dB
(half space)Equalisation N/A Boost Frequency +6 dB @ 40 Hz–90 Hz, Q=1 Indicators
Power LED Blue Signal LED Green Limit LED Red Clip LED N/A Circuit Protection
Amplifier Protection Full short circuit, thermal, overcurrent, DC LF/HF Driver
Max Output Power 2200 W Audio Inputs
Input Sensitivity +4 dBu @ centre position for full rated power Input Impedance 10 kO unblanced, 20 kO balanced Power Supply, Voltage (Fuses)
USA / Canada 100–120 V~, T 12 A H 250 V UK / Australia / Europe 220–240 V~, T 6.3 A H 250 V China 220–240 V~, T 6.3 A H 250 V Japan 100–120 V~, T 12 A H 250 V Power consumption@ 1/8 max power 280 W Rigging options N/A Construction / Dimensions / Weight
Construction Birch plywood, screwed and glued Dimensions (H x W x D) 590 x 640 x 530 mm (23.2 x 25.2 x 20.9″) Net weight 48 kg (105.6 lbs)
