DELTA-AXF15
System Type: Active 15″ 2-Way Bi-Amplified Loudspeaker
Key Features:
-
Power: 800W Continuous, 1600W Peak
-
Frequency Response: 50Hz – 20kHz (±3dB), 45Hz – 20kHz (-10dB)
-
Max SPL: 131.5 dB @ 1m
-
Dispersion: 90° x 45°
-
Drivers:
-
LF: 15″ (404mm) with 3″ (75mm) voice coil, 4Ω
-
HF: 2″ (51.2mm) titanium compression driver, 1″ (25mm) exit, 8Ω
-
-
Amplifiers: Class D
-
LF: 700W Continuous / 1400W Peak
-
HF: 100W Continuous / 200W Peak
-
-
Protection: Thermal shutdown, clip limiter (~650W activation), DC/short protection.
-
Inputs: Same as AXF12 (XLR/TRS combo, RCA, mic/line switchable).
-
Controls: Same as AXF12.
-
Output: XLR line-level (LOOP/MIX switchable).
-
Power Supply: Same as AXF12.
-
Dimensions (HxWxD):
-
Unpacked: 700mm x 446mm x 406mm (27.56″ x 17.56″ x 15.98″)
-
Packed: 803mm x 638mm x 498mm (31.6″ x 25.1″ x 19.6″)
-
-
Weight:
-
Net: 30.5kg (67.1 lbs), Gross: 35.4kg (77.9 lbs).
-
