The TASCAM LM-8ST is a professional eight-channel stereo line mixer designed for permanent installations, studio submixing, keyboard rigs, live sound systems, restaurants, conference facilities and other applications requiring several stereo audio sources to be combined in a compact rack-mounted unit.

It provides eight stereo line-input channels, equivalent to 16 individual balanced line-input connections. Each channel can be routed independently to the ST1 main stereo bus and the configurable ST2/AUX stereo bus.

The ST2/AUX bus can operate as a second independent stereo output or as a post-fader auxiliary send. This makes the LM-8ST suitable for creating two separate stereo mixes, feeding different rooms or zones, sending audio to recording equipment, or adding extra stereo inputs to a larger mixing console.

Key Features

• Eight stereo line-input channels
• 16 balanced 6.3 mm TRS line-input connections
• Additional balanced XLR microphone input on Channel 1
• Four-bus architecture: ST1 left/right and ST2/AUX left/right
• Two independently controlled stereo output buses
• ST2/AUX bus selectable between pre-fader ST2 and post-fader AUX operation
• Individual ST1 and ST2/AUX level controls for every channel
• Switchable +4 dBu and −10 dBV input sensitivity for each channel
• Balanced XLR stereo outputs
• Unbalanced RCA stereo outputs
• Balanced master-bus input and output
• Supports cascading multiple LM-8ST mixers
• Signal and overload indicators on every input channel
• Four-segment stereo LED output meters
• Mono switching for both stereo output buses
• High-power headphone amplifier
• 6.3 mm and 3.5 mm headphone connections
• Selectable headphone-monitoring source
• Ground terminal and ground-lift switch
• Universal 100–240V AC power supply
• Compact 1U 19-inch rack-mountable construction
