The TASCAM MZ-372 is a professional seven-channel analogue installation mixer designed for hotels, conference centres, restaurants, bars, schools, houses of worship, public facilities and entertainment venues.

It provides six flexible input channels, each capable of accepting stereo line sources or balanced microphone/line signals, plus an additional front-panel microphone channel for announcements. Two independently controlled main stereo outputs, a stereo sub output and a monitor output provide flexible audio distribution for permanent installations.

Mixer Type

The TASCAM MZ-372 is an analogue rackmount installation mixer.

It has:

• Seven mixer channels
• Six main mic/line or stereo-source channels
• One additional front-panel microphone channel
• Two main stereo output pairs
• One stereo sub output
• One stereo monitor output

It does not include Bluetooth, USB audio, digital recording, built-in effects or a power amplifier. External power amplifiers or active loudspeakers are required.

Key Features

• Seven analogue input channels
• Six main mixer channels with 100 mm faders
• Additional front-panel microphone channel
• Twelve stereo RCA line-input pairs
• Six balanced XLR mic/line inputs
• Up to 19 selectable input-source sets
• Channels 2, 3 and 4 switchable to phono level
• Direct connection for compatible turntables
• Gain adjustment on Channels 1–6
• Three-band EQ on Channels 1–6
• Five-segment LED level meter on each main channel
• Source-selection controls for every main channel
• Two-band EQ on the front microphone channel
• Automatic microphone talkover function
• Two independently controlled main stereo outputs
• Balanced XLR and unbalanced RCA main outputs
• Stereo sub output with mono/stereo selection
• Independent stereo monitor output
• Pre-fader listening
• Headphone monitoring
• Ten-segment stereo main-output meters
• 3U 19-inch rackmount design
